Spatial Metrics and Habitat Conversion for Extinction Risk Assessment

A spatial analytical framework for preliminary species extinction-risk screening following the IUCN Red List Criterion B guidelines. From occurrence points it computes the Extent of Occurrence (EOO) and Area of Occupancy (AOO) on a data-centred equal-area projection, assigns provisional Criterion B categories, and integrates 'MapBiomas' land-use/land-cover data to quantify the proportion of anthropogenic conversion versus remaining natural habitat within each range metric, with per-class breakdowns and land-cover time series. Several 'MapBiomas' initiatives are supported through one standardised legend - 'MapBiomas' Brazil, the Pan-Amazon / Amazonia collection (RAISG), Colombia, Argentina, Bolivia, Chile, Ecuador, Peru, Venezuela, Paraguay and Uruguay - so a species anywhere these products cover can be screened as readily as a Brazilian one. For ranges outside 'MapBiomas' coverage it can fall back to the global 'Esri' / 'Impact Observatory' 10 m annual land cover derived from 'Sentinel-2' (the product behind the 'ArcGIS' Living Atlas Land Cover Explorer), so a species anywhere on Earth can be screened. It also integrates 'MapBiomas' Fire to compute burned-area metrics and fire time series, and quantifies the overlap of the range with protected areas from the global World Database on Protected Areas (WDPA). 'MapBiomas' data are read either locally over the network via 'GDAL' '/vsicurl/' (no 'Google Earth Engine' account required) or server-side through 'Google Earth Engine' (GEE) for large-scale assessments. Outputs include interactive and publication ready maps and charts, spatial (shapefile/'GeoPackage') and raster exports, and a written assessment report (HTML, text or Word). An interactive 'shiny' application ties the whole workflow together for reproducible conservation planning.

mappingAS

mappingAS — Mapping Area of Species. Geographic range metrics (EOO / AOO), land-cover conversion and fire, and protected-area overlap for extinction-risk screening — from raw occurrence points to an interactive app and a written assessment report.

mappingAS is an R package, with an accompanying Shiny application, for screening species against Criterion B of the IUCN Red List. Starting from a set of occurrence points, it estimates each species' geographic range (EOO / AOO), measures how much of that range has been converted to anthropic land cover and how much has burned, quantifies the overlap with protected areas (global WDPA), and packages everything for mapping, inspection, export and reporting. Land-cover conversion is driven by MapBiomas across South America and by the global Esri / Impact Observatory (Sentinel-2) 10 m land cover elsewhere, so a species anywhere on Earth can be screened with the same workflow — no Google Earth Engine account required.

Screening only. The categories produced are provisional — they rest solely on the EOO/AOO size thresholds of Criterion B. They do not replace a formal IUCN assessment, which also requires the sub-conditions of fragmentation/few locations, continuing decline and extreme fluctuation.

What it does

Installation

# install.packages("remotes")
remotes::install_github("lucasbarreirageo/mappingAS")

The core dependencies (sf, terra, leaflet, DT, shiny, bslib, ggplot2, plotly, officer, readxl) are installed automatically — including officer, so the Word report works out of the box.

The local land-cover backend uses GDAL with /vsicurl/ (shipped with terra/sf), so no Google Earth Engine account and no full-mosaic download are needed — only the window covering each species' range is read (and cached on disk). This applies to both MapBiomas and the global Sentinel-2/Esri layer.

The optional Earth Engine backend needs a configured rgee:

install.packages("rgee")
rgee::ee_install()      # creates the Python environment
rgee::ee_Initialize()   # authenticates with your Earth Engine account

Quick start

library(mappingAS)

# 1. Read points (csv / xlsx / shp) — columns are auto-detected
occ <- read_occurrences("my_occurrences.xlsx")

# 2. Run the assessment. `initiative = "auto"` picks MapBiomas for occurrences
#    in South America and the global Sentinel-2/Esri layer elsewhere.
res <- assess_species(occ,
                      initiative = "auto", backend = "local",
                      mapbiomas = TRUE,   # habitat conversion (default)
                      fire      = TRUE,   # burned-area metrics (Brazil)
                      protected = TRUE)   # overlap with protected areas (WDPA)

# 3. Inspect the summary table (one row per species)
res$summary

# 4. Map and charts
map_species(res)                    # leaflet: points + EOO + AOO + land cover (+ fire, protected areas)
plot_conversion(res)                # natural vs. converted, EOO and AOO
mas_plotly(plot_conversion(res))    # same chart, interactive

# 5. A written assessment report
cat(assessment_report(res, output = "text"))
assessment_report(res, output = "docx", file = "assessment.docx")

# 6. Export the ranges as spatial data
export_ranges(res)                    # mappingAS_EOO.shp + mappingAS_AOO.shp
export_ranges(res, format = "gpkg")   # one GeoPackage with eoo and aoo layers
export_ranges(res, zip = TRUE)        # bundled into a single .zip

Bundled example

ex  <- system.file("extdata", "example_occurrences.csv", package = "mappingAS")
res <- assess_species(read_occurrences(ex), backend = "local")
res

The Shiny application

library(mappingAS)
run_app()

Upload a file (.xlsx/.csv/.gpkg/.geojson or a shapefile in a .zip), map the columns if needed, choose the land-cover product (default Auto), the year, the AOO cell size, the source (local / GEE) and which optional modules to run (fire, protected areas), then click Assess. The app is organised as tabs:

• Map — interactive Leaflet map (points, EOO, AOO, land cover, fire, protected areas) with downloads: interactive HTML, a publishable PNG, and the land-cover / fire rasters as GeoTIFF (clipped to the selected EOO/AOO).
• Results — a visual overview per species (stat cards with in-line bars and IUCN category badges) plus a column glossary explaining every field, and the full table (CSV download).
• Conversion — interactive natural-vs-converted chart (EOO and AOO).
• Classes — area and % of every land-cover class inside the EOO/AOO (CSV download).
• Protected areas — overlap metrics, protection chart and the per-area table (CSV download).
• Time Series — land-cover composition over time (interactive stacked area) for the EOO or AOO.
• Fire — burned-area metrics and time series.
• Report — an interpretive, referenced assessment that you can preview and download as Word (.docx); it accumulates the temporal analysis from any Time series / Fire series you calculate. The same tab also builds a self-contained HTML factsheet (factsheet_html()): fill in the taxonomy, supporting information, land use, conservation units, vouchers and reference, add up to four (watermarked) photos, and it embeds those alongside the computed metrics, a top anthropic activities chart and the standard charts — a single portable .html you can open offline or publish (e.g. on GitHub Pages).
• Methods — the methods and references behind the numbers.

A light/dark theme toggle is available in the header.

Exporting ranges (shapefile / GeoPackage / raster)

export_ranges() writes the EOO and AOO polygons (one feature per species by default) with area, conversion and provisional-category attributes attached:

export_ranges(res,
              dir    = "output",      # output directory
              format = "shapefile",   # or "gpkg"
              what   = "both",        # "eoo", "aoo" or "both"
              crs    = 4326,          # output CRS (WGS84 by default)
              aoo_as = "union",       # "union" (1 feature/species) or "cells"
              zip    = FALSE)         # TRUE = bundle everything into a .zip

Because the ESRI Shapefile format limits field names to 10 characters, the attribute table uses compact names (species, eoo_km2/aoo_km2, n_cells, conv_pct, nat_pct, cat_B1/cat_B2, prov_cat, mb_year, mb_coll). The GeoPackage (format = "gpkg") stores both layers (eoo, aoo) in a single file with no field-name limit — the easiest option for QGIS/ArcGIS. By default, a mappingAS_classes.csv with the per-class composition is written too (class_csv = FALSE to skip).

The Shiny Map tab additionally exports the underlying land-cover and fire GeoTIFF rasters, clipped to the selected species' EOO or AOO, as a .zip.

Per-class composition and time series

# Area and % of each land-cover class within the EOO and AOO
ct <- class_table(res)          # species x range (EOO/AOO) x class

# Land-cover composition over time (stacked-area chart, official class colours)
ts <- timeseries_for_species(res, species = "sp1", range = "eoo", by = "class")
plot_timeseries(ts)
mas_plotly(plot_timeseries(ts))  # interactive

# Directly on any geometry
ts2 <- cover_timeseries(my_geometry, years = c(1990, 2000, 2010, 2020), by = "class")

Each year is read separately (one GeoTIFF window per year), so an annual series across the whole record can take a while; increase the year step to speed it up. (The time series uses whichever product the species was assessed with — MapBiomas back to 1985, or Sentinel-2/Esri for 2017–2023.)

Fire and protected areas

# Fire: enable during assessment, then chart the burned-area series
res <- assess_species(occ, fire = TRUE)
fts <- fire_timeseries_for_species(res, species = "sp1", range = "eoo")
plot_fire_timeseries(fts)

# Protected areas (global WDPA)
res <- assess_species(occ, protected = TRUE)
pa_table(res)         # per-protected-area overlap table
plot_protection(res)  # share of the range inside vs. outside protected areas

With protected = TRUE and mapbiomas = TRUE, the summary also reports the habitat that is both natural and inside protected areas (effectively protected natural habitat).

The results table

Key columns (res$summary, also shown with a glossary in the app's Results tab):

Methods in brief

• EOO = area of the minimum convex polygon over the points (≥ 3 unique coordinates; otherwise NA), edges densified along great circles and measured on the WGS84 ellipsoid.
• AOO = number of occupied 2 × 2 km cells × 4 km² (cell size via cell_km), taken as the minimum over several translated grids.
• Subpopulations = the circular-buffer method: a circle of radius subpop_resol_km (default 1/10 of the maximum inter-point distance, Rivers et al. 2010) is drawn around each occurrence, the circles are dissolved, and the disjoint polygons are counted.
• Locations = number of occupied cells of a 10 km grid (loc_km, or a sliding-scale fraction of the max inter-point distance via loc_scale), minimum over translated grids. When protected = TRUE, occurrences inside protected areas are decoupled from those outside (ConR method_protected: "no_more_than_one" counts each protected area with occurrences as one location; "other" grids inside/outside separately). A grid-based screening proxy, not a formal count of locations under a specific threat.
• The subpopulation and location methods follow the spatial rationale popularised by the ConR package (Dauby et al. 2017), cited here for the idea; the mappingAS implementation is independent code.
• Areas are measured on a data-centred Lambert Azimuthal Equal-Area projection, in line with the IUCN guidelines.
• Conversion: land-cover classes are grouped into natural, anthropic, water, not observed and other. The headline index is converted_pct = anthropic / (anthropic + natural) × 100 (terrestrial denominator; water and not-observed excluded by default — set water_in_denominator = TRUE to include water).
• Criterion B thresholds (screening only): EOO < 100 / 5,000 / 20,000 km² and AOO < 10 / 500 / 2,000 km² for CR / EN / VU.

Land-cover backends

• "local" (default) — reads, over the network, only the window of the source GeoTIFF via GDAL /vsicurl/ (MapBiomas national mosaics, or the Sentinel-2/Esri MGRS tiles). No Earth Engine account, no full-mosaic download. The windowed crop is cached on disk and reused for mapping and re-runs; map overlays use a fast decimated read.
• "gee" — computes per-class areas server-side on Google Earth Engine (recommended for very large, e.g. continental, ranges). Requires rgee::ee_Initialize(). Wired for initiative = "brazil" only.

MapBiomas initiatives (Brazil + South America)

assess_species() (and the whole pipeline) takes an initiative argument so a species outside Brazil can be screened with the same workflow — without Google Earth Engine and without a Google Drive download. Every product is streamed year-by-year as Cloud-Optimized GeoTIFFs from the public MapBiomas bucket via GDAL /vsicurl/, exactly like the Brazil backend:

# A species in the Peruvian Amazon, no GEE:
res_pe <- assess_species(occ, initiative = "peru")

# Anywhere in the Amazon basin (Pan-Amazon collection):
res_az <- assess_species(occ, initiative = "amazonia")

year and collection default to each initiative's latest year and native collection. mb_initiatives() lists the products; mb_source_url(), mb_raster_local(), mb_years(), mb_legend(), summarise_conversion() and cover_timeseries() all accept initiative.

One standardised legend. MapBiomas harmonises its pixel codes across initiatives, so mb_legend() returns a single standardised table (same class names, colours and conservation groups) that labels every country's raster consistently — this is what lets a range spanning more than one country be assessed coherently. The country-specific classes (Andinean formations, Glacier, primary/secondary/dwarf forest, scrubland/steppe/fog oasis/peatlands, Pinus/Eucalyptus plantations, salt flat, …) are included; a code absent from a given product simply contributes zero area. MapBiomas Fire is published for Brazil only and is skipped (with a warning) for the other initiatives.

Outside MapBiomas: global Sentinel-2 land cover

For a species whose range falls outside every MapBiomas country, assess_species() can fall back to the global Esri / Impact Observatory 10 m Annual Land Use Land Cover product — the Sentinel-2-derived data behind the ArcGIS Living Atlas Land Cover Explorer. It is streamed the same way as MapBiomas (public Cloud-Optimized GeoTIFFs via GDAL /vsicurl/, no Google Earth Engine and no account), tiled by MGRS grid zone and read only over each range.

# Automatic: try MapBiomas, fall back to Sentinel-2 where it has no data
res <- assess_species(occ, initiative = "auto")

# Force the global Sentinel-2/Esri layer everywhere
res <- assess_species(occ, initiative = "sentinel2")

# Turn the automatic fallback off (out-of-coverage ranges return NA, as before)
res <- assess_species(occ, initiative = "brazil", fallback = "none")

The automatic fallback is on by default (fallback = "sentinel2"). The 9 Sentinel-2 classes are mapped to the same conservation groups as MapBiomas — Trees / Rangeland / Flooded vegetation → natural; Crops / Built area → anthropic (converted); Water excluded; Bare ground and Snow/Ice excluded as ambiguous; Clouds → not observed — so the conversion percentages, per-class tables, donut charts, maps and report all work unchanged. The product actually used is recorded per species in the mapbiomas_initiative column. Years available: 2017–2023 (s2_years()). Helpers: esri_legend(), s2_source_url(), s2_raster_local().

Protected areas: WDPA (global)

Protected-area overlap (assess_species(protected = TRUE)) reads the global World Database on Protected Areas (WDPA) from its public ArcGIS FeatureServer (bounding-box query, cached), standardised to pa_name / pa_category / pa_group columns with IUCN categories mapped to strict-protection (Ia–III) vs sustainable-use (IV–VI). It works anywhere in the world. A local pa_src file (.shp/.gpkg/.geojson) overrides it for offline use. See wdpa_areas().

Caveats and limitations

• The categories are provisional — they exclude fragmentation, decline and fluctuation.
• The AOO is sensitive to grid origin/placement and to sampling effort; the EOO can be inflated by outlying or erroneous records.
• The local backend streams the land-cover window over the network; for very large (continental) ranges prefer backend = "gee".
• Land-cover accuracy varies by product, class, biome and year (e.g. high-altitude grassland and rocky-outcrop mosaics in MapBiomas, or fine-grained mosaics in the 10 m global layer); consult the official documentation of the product used.

Related tools

mappingAS complements other R packages for preliminary, area-based conservation assessment — among them ConR, red and rCAT, as well as the GeoCAT web tool. Its distinguishing focus is coupling the EOO/AOO range metrics with habitat-conversion, fire and protected-area layers (MapBiomas, global Sentinel-2/Esri land cover, and WDPA) in a single reproducible workflow and Shiny app.

Citation

When using this package, please also cite the underlying data and methods:

• MapBiomas — Projeto MapBiomas (Brazil, Amazonia/RAISG, Colombia, Argentina, Bolivia, Chile, Ecuador, Peru, Venezuela, Paraguay and Uruguay collections; https://mapbiomas.org) and MapBiomas Fire Collection 4.
• Esri / Impact Observatory — Karra, K. et al. (2021). Global land use/land cover with Sentinel-2 and deep learning. IGARSS 2021. The 10 m Annual Land Use Land Cover time series (behind the ArcGIS Living Atlas Land Cover Explorer), used outside MapBiomas coverage.
• IUCN — Standards and Petitions Committee. Guidelines for Using the IUCN Red List Categories and Criteria.
• WDPA — UNEP-WCMC and IUCN, Protected Planet: The World Database on Protected Areas (https://www.protectedplanet.net/en).

Licence

MIT © Antônio Lucas Barreira. See the LICENSE file.
