Non-Compartmental Analysis for Campsis Simulation Platform

A flexible and user-friendly non-compartmental analysis (NCA) toolkit designed to work seamlessly with simulated pharmacokinetic data generated using the 'campsis' ecosystem. The package provides a comprehensive framework to compute standard and custom NCA metrics, including exposure (AUC), peak/trough concentrations, half-life and time-above/below thresholds, with support for configurable time windows and summary statistics. 'campsisnca' integrates tightly with 'campsis' and 'campsismod', enabling streamlined workflows from simulation to analysis. In addition, the package provides a JSON-based interface to define NCA analyses, metrics and options using formal schemas, allowing analyses to be created, validated and executed outside of R and facilitating reproducibility, automation and system integration. The package also includes utilities for generating formatted summary tables and exporting results in multiple formats suitable for reporting. Trapezoidal rule implementation for AUC calculation is based on the 'qpNCA' package by Huisman, Jolling, Mehta and Bergsma (2021) , following methodology from Rowland and Tozer (2011, ISBN:978-0-683-07404-8). The package itself is licensed under the GPL (>= 3); the JSON schema files shipped in inst/extdata are licensed separately under the Creative Commons Attribution 4.0 International (CC BY 4.0).

campsisnca

Analyse your simulation output using non-compartmental analysis.

Installation

Install the latest stable release as follows:

devtools::install_github("Calvagone/campsisnca")

Basic use

First import the campsisnca and gtsummary packages as follows:

library(campsisnca)
library(gtsummary)
library(gt)

Example 1: PK metrics at Day 1 and Day 7

Assume some results were simulated with Campsis (see campsis dataframe) :

campsis <- campsisnca::pk_bolus_md
campsis

## # A tibble: 5,000 × 16
##       ID  TIME   ARM   A_DEPOT A_CENTRAL A_PERIPHERAL A_OUTPUT    BW    CL    V2
##    <dbl> <dbl> <dbl>     <dbl>     <dbl>        <dbl>    <dbl> <dbl> <dbl> <dbl>
##  1     1     0     0   0              0           0        0    93.6  5.89  94.8
##  2     1     1     0   4.31e+2      538.         11.3     19.4  93.6  5.89  94.8
##  3     1     2     0   1.86e+2      722.         32.4     59.7  93.6  5.89  94.8
##  4     1     4     0   3.44e+1      741.         71.7    153.   93.6  5.89  94.8
##  5     1     6     0   6.39e+0      657.         96.3    240.   93.6  5.89  94.8
##  6     1     8     0   1.19e+0      574.        108.     316.   93.6  5.89  94.8
##  7     1    12     0   4.09e-2      447.        110.     442.   93.6  5.89  94.8
##  8     1    16     0   1.41e-3      358.         99.8    542.   93.6  5.89  94.8
##  9     1    24     0   1.67e-6      239.         72.7    688.   93.6  5.89  94.8
## 10     1    48     0   1.67e-6      316.         96.4   1588.   93.6  5.89  94.8
## # ℹ 4,990 more rows
## # ℹ 6 more variables: Q <dbl>, V3 <dbl>, KA <dbl>, CP <dbl>, OBS_CP <dbl>,
## #   Y <dbl>

Let’s define our PK metrics at Day 1 and Day 7 as follows:

# Day 1
nca_d1 <- NCAAnalysis(name = "Day 1", window = TimeWindow(0, 24), variable = "Y") %>%
  add(c(AUC(unit = "ng/mL*h"), Cmax(unit = "ng/mL"), Tmax(unit = "h"), Ctrough(unit = "ng/mL")))

# Day 7
nca_d7 <- NCAAnalysis(name = "Day 7", window = TimeWindow(144, 168), variable = "Y") %>%
  add(c(AUC(), Cmax(), Tmax(), Ctrough()))

These 2 metrics may be imported into a metrics table object, as follows. Use the calculate method to calculate the metrics in the table.

table <- NCATable() %>%
  add(c(nca_d1, nca_d7)) %>%
  calculate(campsis)

This table can be exported:

1. To a dataframe using the export function:

table %>% export(dest = "dataframe")

## # A tibble: 24 × 4
##    metric  stat    value analysis
##    <chr>   <chr>   <dbl> <chr>
##  1 AUC     median 134.   Day 1
##  2 AUC     p5     102.   Day 1
##  3 AUC     p95    168.   Day 1
##  4 Cmax    median  10.2  Day 1
##  5 Cmax    p5       7.85 Day 1
##  6 Cmax    p95     13.1  Day 1
##  7 tmax    median   2    Day 1
##  8 tmax    p5       1    Day 1
##  9 tmax    p95      6    Day 1
## 10 Ctrough median   2.89 Day 1
## # ℹ 14 more rows

When type is not specified, default value is summary. Argument type can also be summary_wide or summary_pretty. In the latter case, summary statistics are exported according to the arguments stat_display and digits provided for each metric.

1. To an HTML table using gt:

table %>% export(dest = "gt") %>% as_raw_html()

Please note the individual metrics can also be exported to a dataframe using the export function as follows:

table %>% export(dest = "dataframe", type = "individual_wide")

## # A tibble: 400 × 6
##       id analysis   AUC  Cmax  tmax Ctrough
##    <dbl> <chr>    <dbl> <dbl> <dbl>   <dbl>
##  1     1 Day 1    122.   9.78     4    2.75
##  2     2 Day 1     92.6  6.11     6    1.70
##  3     3 Day 1    119.  10.9      2    1.97
##  4     4 Day 1    131.   9.72     2    1.99
##  5     5 Day 1    166.  10.1      4    3.79
##  6     6 Day 1    152.  10.1      2    3.04
##  7     7 Day 1    134.   9.28     2    2.70
##  8     8 Day 1    163.  13.7      2    2.91
##  9     9 Day 1    111.   9.62     2    1.94
## 10    10 Day 1    118.   9.91     4    2.90
## # ℹ 390 more rows

Example 2: PK metrics at Day 1 and Day 7 for different body weight ranges

library(dplyr)
campsis_ <- campsis %>%
  mutate(Scenario = ifelse(BW >= 75, ">=75kg patients", "<75kg patients"))

day1 <- NCAAnalysis(name = "Day 1", window = TimeWindow(0, 24), variable = "Y", strata = c(Scenario = "all")) %>%
  add(c(AUC(unit = "ng/mL*h"), Cmax(unit = "ng/mL"), Tmax(unit = "h"), Ctrough(unit = "ng/mL")))

day7 <- NCAAnalysis(name = "Day 7", window = TimeWindow(144, 168), variable = "Y", strata = c(Scenario = "all")) %>%
  add(c(AUC(), Cmax(), Tmax(), Ctrough()))

table <- NCATable() %>%
  add(c(day1, day7)) %>%
  calculate(campsis_)

table %>% export(dest = "gt") %>% as_raw_html()

# Alternatively, first stratification variable can be seen in columns (use of 'tbl_merge' within gtsummary)
table <- NCATable(combine_with = "tbl_merge") %>%
  add(c(day1, day7)) %>%
  calculate(campsis_)

table %>% export(dest = "gt") %>% as_raw_html()

Example 3: Calculate 2-compartment half-life metrics

nca <- NCAAnalysis(variable = "Y") %>%
  add(c(Thalf.2cpt.dist(), Thalf.2cpt.eff(), Thalf.2cpt.z()))

table <- NCATable() %>%
  add(nca) %>%
  calculate(campsis %>% mutate(DOSE = 1000, TAU = 24))

table %>% export(dest = "gt") %>% as_raw_html()

Example 4: Compute terminal half-live based on data

nca <- NCAAnalysis(variable = "Y") %>%
  add(c(Thalf(window = TimeWindow(7 * 24, 10 * 24))))

table <- NCATable() %>%
  add(nca) %>%
  calculate(campsis)

table %>% export(dest = "gt") %>% as_raw_html()

Example 5: Round your PK metrics

# Day 1
nca_d1 <- NCAAnalysis(name = "Day 1", window = TimeWindow(0, 24), variable = "Y") %>%
  add(AUC(digits = ~ style_sigfig(.x, 2), name = "AUC1")) %>% # At least 2 significant figures (default in gtsummary)
  add(AUC(digits = c(1, 2, 2), name = "AUC2")) %>% # Respectively 1/2/2 digit(s) after decimal for med, p5 and p95
  add(AUC(digits = ~ signif(.x, 2), name = "AUC3")) %>% # 2 significant digits only
  add(AUC(digits = list(~ round(.x / 5) * 5, ~ round(.x, 1), ~ style_number(.x)), name = "AUC4")) # 1 specific function for med, p5 and p95

# Day 7
nca_d7 <- NCAAnalysis(name = "Day 7", window = TimeWindow(144, 168), variable = "Y") %>%
  add(AUC(name = "AUC1")) %>%
  add(AUC(name = "AUC2")) %>%
  add(AUC(name = "AUC3")) %>%
  add(AUC(name = "AUC4"))

table <- NCATable()
table <- table %>%
  add(c(nca_d1, nca_d7)) %>%
  calculate(campsis)

table %>% export(dest = "gt") %>% as_raw_html()

Example 6: Export custom metrics (including categorical data)

# Compute Cmax yourself using campsisnca
custom1 <- CustomMetric(fun = ~ Cmax() %>% i_value(.x, .y), name = "C_{max} custom", unit = "ng/mL")

# Check if Cmax if higher than 12 ng/mL
custom2 <- CustomMetric(
  fun = ~ (Cmax() %>% i_value(.x, .y)) > 12,
  name = "C_{max} > 12",
  unit = "%",
  categorical = TRUE
)

# Shortcut notation is also accepted
custom3 <- CustomMetric(fun = ~ Cmax > 13, name = "C_{max}> 13", unit = "%", categorical = TRUE)


# Day 1
nca_d1 <- NCAAnalysis(name = "Day 1", window = TimeWindow(0, 24), variable = "Y") %>%
  add(c(Cmax(unit = "ng/mL"), Tmax(unit = "h"), custom1, custom2, custom3))

# Day 7
nca_d7 <- NCAAnalysis(name = "Day 7", window = TimeWindow(144, 168), variable = "Y") %>%
  add(c(Cmax(), Tmax(), custom1, custom2, custom3))

table <- NCATable()
table <- table %>%
  add(c(nca_d1, nca_d7)) %>%
  calculate(campsis)

table %>% export(dest = "gt") %>% as_raw_html()

# Alternatively, all dichotomous levels can be shown as well:
table <- NCATable(show_all_levels = TRUE)
table <- table %>%
  add(c(nca_d1, nca_d7)) %>%
  calculate(campsis)

table %>% export(dest = "gt") %>% as_raw_html()

Example 7: Geometric mean / Geometric CV

nca <- NCAAnalysis(variable = "Y") %>%
  add(c(
    AUC(unit = "ng/mL*h", stat_display = "{geomean} ({geocv}%)"),
    Cavg(unit = "ng/mL", stat_display = "{geomean} ({geocv}%)")
  ))

table <- NCATable() %>%
  add(nca) %>%
  calculate(campsis)

table %>% export(dest = "gt") %>% as_raw_html()

Example 8: Statistics on categorical data with more than 2 levels

get_category <- function(.x, .y) {
  values <- Cmax() %>% i_value(.x, .y)
  retValue <- dplyr::case_when(
    values < 10 ~ "(1) < 10 ng/mL",
    values >= 10 & values <= 15 ~ "(2) 10-15 ng/mL",
    values > 15 ~ "(3) > 15 ng/mL",
  )
  return(retValue)
}

# Or equivalently, the 1-line purrr-style lambda expression
# get_category <- ~case_when(Cmax < 10 ~ "(1) < 10 ng/mL", Cmax >= 10 & Cmax <= 15 ~ "(2) 10-15 ng/mL", Cmax > 15 ~ "(3) > 15 ng/mL")

# Day 1
nca_d1 <- NCAAnalysis(name = "Day 1", window = TimeWindow(0, 1, time_unit = "day"), variable = "Y") %>%
  add(Cmax(unit = "ng/mL")) %>%
  add(CustomMetric(fun = get_category, name = "C_{max} categories", unit = "%", categorical = TRUE))

# Day 7
nca_d7 <- NCAAnalysis(name = "Day 7", window = TimeWindow(6, 7, time_unit = "day"), variable = "Y") %>%
  add(Cmax()) %>%
  add(CustomMetric(fun = get_category, name = "C_{max} categories", unit = "%", categorical = TRUE))

table <- NCATable()
table <- table %>%
  add(c(nca_d1, nca_d7)) %>%
  calculate(campsis)

table %>% export(dest = "gt") %>% as_raw_html()

Example 9: Time above or below a certain threshold

In the example below, we look at the individual time above (or below) 10 ng/mL at Day 1 for the 10 first subjects.

day1 <- campsis %>%
  timerange(0, 24) %>%
  filter(ID %in% (1:10))

campsis::spaghettiPlot(day1, "Y") +
  ggplot2::geom_hline(yintercept = 10, linetype = "dashed", color = "red")

nca <- NCAAnalysis(window = TimeWindow(0, 24), variable = "Y") %>%
  add(Cmax(unit = "ng/mL*h", stat_display = "{mean}")) %>%
  add(TimeAboveLimit(limit = 10, unit = "h", stat_display = "{mean}")) %>%
  add(TimeBelowLimit(limit = 10, unit = "h", stat_display = "{mean}"))

table <- NCATable() %>%
  add(nca) %>%
  calculate(campsis %>% filter(ID %in% (1:10)))

table %>% export(dest = "dataframe", type = "individual_wide")

## # A tibble: 10 × 4
##       id  Cmax `Time above 10` `Time below 10`
##    <dbl> <dbl>           <dbl>           <dbl>
##  1     1  9.78           0                24
##  2     2  6.11           0                24
##  3     3 10.9            0.829            23.2
##  4     4  9.72           0                24
##  5     5 10.1            0.427            23.6
##  6     6 10.1            0.186            23.8
##  7     7  9.28           0                24
##  8     8 13.7            4.94             19.1
##  9     9  9.62           0                24
## 10    10  9.91           0                24

Summary statistics can also be exported:

table %>% export(dest = "gt") %>% as_raw_html()

Example 10: Summary statistics across arms and scenarios

Let’s generate some fictitious results where two treatment arms are simulated (1g QD and 2g QD) and where scenarios are included too (Base scenario and Lower clearance).

library(campsis)
arm1 <- Arm(subjects = 24, label = "1g QD") %>%
  add(Bolus(time = 0, amount = 1000, compartment = "ABS", ii = 24, addl = 6)) %>%
  add(Observations(seq(0, 14 * 24, by = 0.1))) # 2-weeks observations

arm2 <- Arm(subjects = 24, label = "0.5g BID") %>%
  add(Bolus(time = 0, amount = 500, compartment = "ABS", ii = 12, addl = 13)) %>%
  add(Observations(seq(0, 14 * 24, by = 0.1))) # 2-weeks observations

dataset <- Dataset() %>%
  add(c(arm1, arm2))

scenario1 <- Scenario(name = "Base scenario", model = ~.x, dataset = ~.x)
scenario2 <- Scenario(
  name = "Lower clearance",
  model = ~ .x %>%
    replace(Theta(name = "CL", value = 2)),
  dataset = ~.x
)
scenarios <- Scenarios() %>% add(c(scenario1, scenario2))
results <- simulate(
  model = model_suite$pk$`2cpt_fo`,
  dataset = dataset,
  seed = 1,
  dest = "mrgsolve",
  scenarios = scenarios
)

shadedPlot(results, "CONC", colour = "ARM", strat_extra = "SCENARIO") +
  ggplot2::facet_wrap(~SCENARIO) +
  ggplot2::xlab("Time (h)") +
  ggplot2::ylab("Concentrations (ng/mL)") +
  ggplot2::labs(colour = "Arm", fill = "Arm")

NCA summary statistics are automatically calculated across all strata levels in ARM and SCENARIO.

nca <- NCAAnalysis(name = "Day 7", window = TimeWindow(144, 168), variable = "CONC") %>%
  add(AUC(unit = "ng/mL*h")) %>%
  add(Cmax(unit = "ng/mL")) %>%
  add(CustomMetric(
    fun = ~ (Cmax() %>% i_value(.x, .y)) > 30,
    name = "C_{max} > 30",
    unit = "%",
    categorical = TRUE
  )) %>%
  add(Tmax(unit = "h", digits = 2)) %>%
  add(Ctrough(unit = "ng/mL")) %>%
  add(Thalf(unit = "h", window = TimeWindow(200, "last"))) # Thalf will be estimated by dosing a linear regression on the range [200, 'last']

table <- NCATable() %>%
  add(nca) %>%
  calculate(results)

table %>% export(dest = "gt") %>% as_raw_html()

In the previous example, statistics are summarized on Day 7. In you wish specifics statistics for each one of your arms, you could also proceed sightly differently by creating 2 analyses (1 for each strata) and refer to specific arms by overriding the default strata.

nca_arm1 <- NCAAnalysis(
  name = "Last dose in '1g QD' arm",
  window = TimeWindow(144, 168),
  variable = "CONC",
  strata = c(ARM = "1g QD", SCENARIO = "all")
) %>%
  add(AUC(unit = "ng/mL*h")) %>%
  add(Cmax(unit = "ng/mL")) %>%
  add(CustomMetric(
    fun = ~ (Cmax() %>% i_value(.x, .y)) > 30,
    name = "C_{max} > 30",
    unit = "%",
    categorical = TRUE
  )) %>%
  add(Tmax(unit = "h", digits = 2)) %>%
  add(Ctrough(unit = "ng/mL")) %>%
  add(Thalf(unit = "h", window = TimeWindow(200, "last")))

nca_arm2 <- NCAAnalysis(
  name = "Last dose in '0.5 BID' arm",
  window = TimeWindow(156, 168),
  variable = "CONC",
  strata = c(ARM = "0.5g BID", SCENARIO = "all")
) %>%
  add(AUC(unit = "ng/mL*h")) %>%
  add(Cmax(unit = "ng/mL")) %>%
  add(CustomMetric(
    fun = ~ (Cmax() %>% i_value(.x, .y)) > 30,
    name = "C_{max} > 30",
    unit = "%",
    categorical = TRUE
  )) %>%
  add(Tmax(unit = "h", digits = 2)) %>%
  add(Ctrough(unit = "ng/mL")) %>%
  add(Thalf(unit = "h", window = TimeWindow(200, "last")))

table <- NCATable() %>%
  add(nca_arm1) %>%
  add(nca_arm2) %>%
  calculate(results)

table %>% export(dest = "gt") %>% as_raw_html()
