Child Anthropometry z-Score Calculator

A tool for calculating z-scores and centiles for weight-for-age, length/height-for-age, weight-for-length/height, BMI-for-age, head circumference-for-age, age circumference-for-age, subscapular skinfold-for-age, triceps skinfold-for-age based on the WHO Child Growth Standards.


Project Status: Active – The project has reached a stable, usablestate and is being activelydeveloped. lifecycle CRAN_Status_Badge CRAN CRAN CRAN Travis-CI BuildStatus AppVeyor BuildStatus codecov DOI

zscorer facilitates the calculation of z-scores (i.e. the number of standard deviations from the mean) for key anthropometric indices used to assess early childhood growth: weight-for-age (WFA), height-for-age (HFA), weight-for-height (WFH), BMI-for-age (BFA), arm circumference-for-age (ACFA), head circumference-for-age (HCFA), subscapular skinfold-for-age (SSFA) and triceps skinfold-for-age (TSFA). zscorer refers to the results of the WHO Multicentre Growth Reference Study as standard for calculating the z-scores hence it comes as a dataset in this package.

zscorer calculates the z-score for the corresponding anthropometric index given a dataset of children containing anthropometric measurements for height, weight, arm circumference, head circumference, subscapular skinfold, and triceps skinfold and additional data on age and sex to assess growth and nutritional status of the sample of children against the WHO Multicentre Growth Reference Study standard (WGS).

zscorer also contains functions that calculates the zscore for three commonly assessed anthropometric indices in nutrition surveys (weight-for-height, height-for-age, weight-for-age) given anthropometric measurements of individual children. These are legacy functions used in earlier versions of zscorer that will soon be deprecated.

Installation

You can install zscorer from CRAN:

install.packages("zscorer")

or you can install the development version of zscorer from GitHub with:

if(!require(devtools) { install.packages("devtools") }
devtools::install_github("nutriverse/zscorer")

then load zscorer

# load package
library(zscorer)

Usage

Calculating anthropometric z-scores using the addWGSR() function

The main function in the zscorer package is addWGSR().

To demonstrate its usage, we will use the accompanying dataset in zscorer called anthro3. We inspect the dataset as follows:

head(anthro3)

which returns:

#>   psu age sex weight height muac oedema
#> 1   1  10   1    5.7   64.2  125      2
#> 2   1  10   2    5.8   64.4  121      2
#> 3   1   9   2    6.5   62.2  139      2
#> 4   1  11   9    6.5   64.9  129      2
#> 5   1  24   2    6.5   72.9  120      2
#> 6   1  12   2    6.6   69.4  126      2

anthro3 contains anthropometric data from a Rapid Assessment Method (RAM) survey from Burundi.

Anthropometric indices (e.g. weight-for-height z-scores) have not been calculated and added to the data.

We will use the addWGSR() function to add weight-for-height (wfh) z-scores to the example data:

svy <- addWGSR(data = anthro3, sex = "sex", firstPart = "weight",
               secondPart = "height", index = "wfh")
#> ===========================================================================

A new column named wfhz has been added to the dataset:

#>   psu age sex weight height muac oedema  wfhz
#> 1   1  10   1    5.7   64.2  125      2 -2.73
#> 2   1  10   2    5.8   64.4  121      2 -2.04
#> 3   1   9   2    6.5   62.2  139      2  0.13
#> 4   1  11   9    6.5   64.9  129      2    NA
#> 5   1  24   2    6.5   72.9  120      2 -3.44
#> 6   1  12   2    6.6   69.4  126      2 -2.26

The wfhz column contains the weight-for-height (wfh) z-scores calculated from the sex, weight, and height columns in the anthro3 dataset. The calculated z-scores are rounded to two decimals places unless the digits option is used to specify a different precision (run ?addWGSR to see description of various parameters that can be specified in the addWGSR() function).

The addWGSR() function takes up to nine parameters to calculate each index separately, depending on the index required. These are described in the Help files of the zscorer package which can be accessed as follows:

?addWGSR

The standing parameter specifies how “stature” (i.e. length or height) was measured. If this is not specified, and in some special circumstances, height and age rules will be applied when calculating z-scores. These rules are described in the table below.

index standing age height Action
hfa or lfa standing < 731 days index = lfa height = height + 0.7 cm
hfa or lfa supine < 731 days index = lfa
hfa or lfa unknown < 731 days index = lfa
hfa or lfa standing ≥ 731 days index = hfa
hfa or lfa supine ≥ 731 days index = hfa height = height - 0.7 cm
hfa or lfa unknown ≥ 731 days index = hfa
wfh or wfl standing < 65 cm index = wfl height = height + 0.7 cm
wfh or wfl standing ≥ 65 cm index = wfh
wfh or wfl supine ≤ 110 cm index = wfl
wfh or wfl supine more than 110 cm index = wfh height = height - 0.7 cm
wfh or wfl unknown < 87 cm index = wfl
wfh or wfl unknown ≥ 87 cm index = wfh
bfa standing < 731 days height = height + 0.7 cm
bfa standing ≥ 731 days height = height - 0.7 cm

The addWGSR() function will not produce error messages unless there is something very wrong with the data or the specified parameters. If an error is encountered in a record then the value NA is returned. Error conditions are listed in the table below.

Error condition Action
Missing or nonsense value in standing parameter Set standing to 3 (unknown) and apply appropriate height or age rules.
Unknown index specified Return NA for z-score.
Missing sex Return NA for z-score.
Missing firstPart Return NA for z-score.
Missing secondPart Return NA for z-score.
sex is not male (1) or female (2) Return NA for z-score.
firstPart is not numeric Return NA for z-score.
secondPart is not numeric Return NA for z-score.
Missing thirdPart when index = "bfa" Return NA for z-score.
thirdPart is not numeric when index = "bfa" Return NA for z-score.
secondPart is out of range for specified index Return NA for z-score.

We can see this error behaviour using the example data:

table(is.na(svy$wfhz))
#>
#> FALSE  TRUE
#>   220     1

We can display the problem record:

svy[is.na(svy$wfhz), ]
#>   psu age sex weight height muac oedema wfhz
#> 4   1  11   9    6.5   64.9  129      2   NA

The problem is due to the value 9 in the sex column, which should be coded 1 (for male) and 2 (for female). Z-scores are only calculated for records with sex specified as either 1 (male) or 2 (female). All other values, including NA, will return NA.

The addWGSR() function requires that data are recorded using the required units or required codes (see Table Z1).

The addWGSR() function will return incorrect values if the data are not recorded using the required units. For example, this attempt to add weight-for-age z-scores to the example data:

svy <- addWGSR(data = svy, sex = "sex", firstPart = "weight",
               secondPart = "age", index = "wfa")
#> ===========================================================================

will give incorrect results:

summary(svy$wfaz)
#>    Min. 1st Qu.  Median    Mean 3rd Qu.    Max.    NA's
#>   3.450   7.692   9.840   9.684  11.430  15.900       1

The odd range of values is due to age being recorded in months rather than days.

It is simple to convert all ages from months to days:

svy$age <- svy$age * (365.25 / 12)
head(svy)
#>   psu      age sex weight height muac oedema  wfhz wfaz
#> 1   1 304.3750   1    5.7   64.2  125      2 -2.73 3.45
#> 2   1 304.3750   2    5.8   64.4  121      2 -2.04 3.95
#> 3   1 273.9375   2    6.5   62.2  139      2  0.13 5.12
#> 4   1 334.8125   9    6.5   64.9  129      2    NA   NA
#> 5   1 730.5000   2    6.5   72.9  120      2 -3.44 3.82
#> 6   1 365.2500   2    6.6   69.4  126      2 -2.26 5.01

before calculating and adding weight-for-age z-scores:

svy <- addWGSR(data = svy, sex = "sex", firstPart = "weight",
               secondPart = "age", index = "wfa")
#> ===========================================================================
head(svy)
#>   psu      age sex weight height muac oedema  wfhz  wfaz
#> 1   1 304.3750   1    5.7   64.2  125      2 -2.73 -4.13
#> 2   1 304.3750   2    5.8   64.4  121      2 -2.04 -3.19
#> 3   1 273.9375   2    6.5   62.2  139      2  0.13 -1.97
#> 4   1 334.8125   9    6.5   64.9  129      2    NA    NA
#> 5   1 730.5000   2    6.5   72.9  120      2 -3.44 -4.61
#> 6   1 365.2500   2    6.6   69.4  126      2 -2.26 -2.56
summary(svy$wfaz)
#>    Min. 1st Qu.  Median    Mean 3rd Qu.    Max.    NA's
#>  -4.610  -1.873  -1.085  -1.154  -0.480   2.600       1

The muac column in the example dataset is recorded in millimetres (mm). We need to convert this to centimetres (cm):

svy$muac <- svy$muac / 10
head(svy)
#>   psu      age sex weight height muac oedema  wfhz  wfaz
#> 1   1 304.3750   1    5.7   64.2 12.5      2 -2.73 -4.13
#> 2   1 304.3750   2    5.8   64.4 12.1      2 -2.04 -3.19
#> 3   1 273.9375   2    6.5   62.2 13.9      2  0.13 -1.97
#> 4   1 334.8125   9    6.5   64.9 12.9      2    NA    NA
#> 5   1 730.5000   2    6.5   72.9 12.0      2 -3.44 -4.61
#> 6   1 365.2500   2    6.6   69.4 12.6      2 -2.26 -2.56

before using the addWGS() function to calculate MUAC-for-age z-scores:

svy <- addWGSR(svy, sex = "sex", firstPart = "muac",
               secondPart = "age", index = "mfa")
#> ===========================================================================
head(svy)
#>   psu      age sex weight height muac oedema  wfhz  wfaz  mfaz
#> 1   1 304.3750   1    5.7   64.2 12.5      2 -2.73 -4.13 -1.97
#> 2   1 304.3750   2    5.8   64.4 12.1      2 -2.04 -3.19 -1.88
#> 3   1 273.9375   2    6.5   62.2 13.9      2  0.13 -1.97 -0.14
#> 4   1 334.8125   9    6.5   64.9 12.9      2    NA    NA    NA
#> 5   1 730.5000   2    6.5   72.9 12.0      2 -3.44 -4.61 -2.70
#> 6   1 365.2500   2    6.6   69.4 12.6      2 -2.26 -2.56 -1.46

As a last example we will use the addWGSR() function to add body mass index-for-age (bfa) z-scores to the data to create a new variable called bmiAgeZ with a precision of 4 decimal places as:

svy <- addWGSR(data = svy, sex = "sex", firstPart = "weight",
               secondPart = "height", thirdPart = "age", index = "bfa",
               output = "bmiAgeZ", digits = 4)
#> ===========================================================================
head(svy)
#>   psu      age sex weight height muac oedema  wfhz  wfaz  mfaz bmiAgeZ
#> 1   1 304.3750   1    5.7   64.2 12.5      2 -2.73 -4.13 -1.97 -2.6928
#> 2   1 304.3750   2    5.8   64.4 12.1      2 -2.04 -3.19 -1.88 -2.0005
#> 3   1 273.9375   2    6.5   62.2 13.9      2  0.13 -1.97 -0.14  0.0405
#> 4   1 334.8125   9    6.5   64.9 12.9      2    NA    NA    NA      NA
#> 5   1 730.5000   2    6.5   72.9 12.0      2 -3.44 -4.61 -2.70 -2.8958
#> 6   1 365.2500   2    6.6   69.4 12.6      2 -2.26 -2.56 -1.46 -2.0796

Usage - legacy functions

Calculating z-score for each of the three anthropometric indices for a single child

For this example, we will use the getWGS() function and apply it to dummy data of a 52 month old male child with a weight of 14.6 kg and a height of 98.0 cm.

# weight-for-age z-score
waz <- getWGS(sexObserved = 1,     # 1 = Male / 2 = Female
              firstPart = 14.6,    # Weight in kilograms up to 1 decimal place
              secondPart = 52,     # Age in whole months
              index = "wfa")       # Anthropometric index (weight-for-age)

waz
#> [1] -1.187651

# height-for-age z-score
haz <- getWGS(sexObserved = 1,
              firstPart = 98,      # Height in centimetres
              secondPart = 52,
              index = "hfa")       # Anthropometric index (height-for-age)

haz
#> [1] -1.741175

# weight-for-height z-score
whz <- getWGS(sexObserved = 1,
              firstPart = 14.6,
              secondPart = 98,
              index = "wfh")       # Anthropometric index (weight-for-height)

whz
#> [1] -0.1790878

Applying the getWGS() function results in a calculated z-score for one child.

Calculating z-score for each of the three anthropometric indices for a cohort or sample of children

For this example, we will use the getCohortWGS() function and apply it to sample data anthro1 that came with zscorer.

# Make a call for the anthro1 dataset
anthro1

As you will see, this dataset has the 4 variables you will need to use with getCohortWGS() to calculate the z-score for the corresponding anthropometric index. These are age, sex, weight and height.

head(anthro1)
#>   psu age sex weight height muac oedema   haz   waz   whz flag
#> 1   1   6   1    7.3   65.0  146      2 -1.23 -0.76  0.06    0
#> 2   1  42   2   12.5   89.5  156      2 -2.35 -1.39 -0.02    0
#> 3   1  23   1   10.6   78.1  149      2 -2.95 -1.06  0.57    0
#> 4   1  18   1   12.8   81.5  160      2 -0.28  1.42  2.06    0
#> 5   1  52   1   12.1   87.3  152      2 -4.21 -2.68 -0.14    0
#> 6   1  36   2   16.9   93.0  190      2 -0.54  1.49  2.49    0

To calculate the three anthropometric indices for all the children in the sample, we execute the following commands in R:

# weight-for-age z-score
waz <- getCohortWGS(data = anthro1,
                    sexObserved = "sex",
                    firstPart = "weight",
                    secondPart = "age",
                    index = "wfa")
head(waz, 50)
#>  [1] -0.75605549 -1.39021503 -1.05597853  1.41575096 -2.67757242
#>  [6]  1.49238050 -0.12987704 -0.02348159 -1.50647344 -1.54381630
#> [11] -2.87495712 -0.43497240 -1.03899540 -1.69281855 -1.31245898
#> [16] -2.21003260 -0.01189226 -0.90917762 -0.67839855 -0.94746695
#> [21] -2.49960425 -0.95659644 -1.65442686 -1.25052760  0.67335751
#> [26]  0.30156301  0.24261346 -2.78670709 -1.15820651 -1.15477183
#> [31] -1.35540820 -0.59134959 -4.14967218 -0.45748752 -0.74331669
#> [36] -1.69725836 -1.05745067 -0.18869508 -0.42095770 -2.21030414
#> [41] -1.30536715 -3.63778143 -0.60662526 -0.54360470 -1.59171780
#> [46] -1.74745738 -0.34803338  0.69896149 -0.74467130  0.18924572

# height-for-age z-score
haz <- getCohortWGS(data = anthro1,
                    sexObserved = "sex",
                    firstPart = "height",
                    secondPart = "age",
                    index = "hfa")
head(haz, 50)
#>  [1] -1.2258169 -2.3475886 -2.9518041 -0.2812852 -4.2056663 -0.5387678
#>  [7] -2.4020719 -1.0317699 -2.7410884 -4.7037571 -2.5670550 -2.1144960
#> [13] -2.2323505 -2.3155458 -2.7516165 -2.7930694  0.1121349 -1.9001797
#> [19] -2.9543730 -1.9671042 -3.8716522  0.8667206 -2.8252069 -2.1412285
#> [25] -2.7994643  0.5496459 -1.4372002 -3.7979410 -2.5661752 -1.8301183
#> [31] -1.6548589 -2.7110333 -3.6399642 -1.7955069 -1.6775100 -1.0317699
#> [37] -0.4356881 -1.2660152  0.4990326 -4.6085660 -3.1662351 -1.0695930
#> [43] -1.8477936 -2.5502314 -1.8301183 -2.2755493 -3.2816532  0.4876774
#> [49] -2.4396410 -0.4794744

# weight-for-height z-score
whz <- getCohortWGS(data = anthro1,
                    sexObserved = "sex",
                    firstPart = "weight",
                    secondPart = "height",
                    index = "wfh")
head(whz, 50)
#>  [1]  0.05572347 -0.01974903  0.57469112  2.06231749 -0.14080044
#>  [6]  2.49047246  1.83315197  0.93614891  0.18541943  2.11599287
#> [11] -1.96943887  1.06351047  0.35315830 -0.61151003 -0.01049441
#> [16] -0.75038993 -0.08000322  0.31277573  1.56456175  0.22152087
#> [21] -0.08798757 -2.14197877 -0.30804823  0.00778227  3.21041413
#> [26]  0.07434468  1.40966986 -0.81485050  0.63816647 -0.33540392
#> [31] -0.61955533  1.35716952 -2.77364671  1.00831095  0.32842063
#> [36] -1.66705281 -1.21157702  0.89024472 -0.89865037  0.82166393
#> [41]  0.64442137 -4.39847850  0.38411140  1.48299847 -0.93068495
#> [46] -0.88558228  1.69551410  0.65143649  0.61269397  0.59813891

Applying the getCohortWGS() function results in a vector of calculated z-scores for all children in the cohort or sample.

Calculating z-scores for all of the three anthropometric indices in one function

For this example, we will use the getAllWGS() function and apply it to sample data anthro1 that came with zscorer.

# weight-for-age z-score
zScores <- getAllWGS(data = anthro1,
                     sex = "sex",
                     weight = "weight",
                     height = "height",
                     age = "age",
                     index = "all")
head(zScores, 20)
#>            waz        haz         whz
#> 1  -0.75605549 -1.2258169  0.05572347
#> 2  -1.39021503 -2.3475886 -0.01974903
#> 3  -1.05597853 -2.9518041  0.57469112
#> 4   1.41575096 -0.2812852  2.06231749
#> 5  -2.67757242 -4.2056663 -0.14080044
#> 6   1.49238050 -0.5387678  2.49047246
#> 7  -0.12987704 -2.4020719  1.83315197
#> 8  -0.02348159 -1.0317699  0.93614891
#> 9  -1.50647344 -2.7410884  0.18541943
#> 10 -1.54381630 -4.7037571  2.11599287
#> 11 -2.87495712 -2.5670550 -1.96943887
#> 12 -0.43497240 -2.1144960  1.06351047
#> 13 -1.03899540 -2.2323505  0.35315830
#> 14 -1.69281855 -2.3155458 -0.61151003
#> 15 -1.31245898 -2.7516165 -0.01049441
#> 16 -2.21003260 -2.7930694 -0.75038993
#> 17 -0.01189226  0.1121349 -0.08000322
#> 18 -0.90917762 -1.9001797  0.31277573
#> 19 -0.67839855 -2.9543730  1.56456175
#> 20 -0.94746695 -1.9671042  0.22152087

Applying the getAllWGS() function results in a data frame of calculated z-scores for all children in the cohort or sample for all the anthropometric indices.

News

zscorer 0.2.0

Second relase of zscorer. In this release:

  • created overall function to calculate all anthropometric indices included in the WHO Growth Standards;

  • updated README to illustrate use of main overall function for calculating anthropometric indices;

  • added vignettes to describe calculation of anthropometric indices

  • udpate Shiny application

zscorer 0.1.0

Initial release of zscorer

Reference manual

It appears you don't have a PDF plugin for this browser. You can click here to download the reference manual.

install.packages("zscorer")

0.2.0 by Ernest Guevarra, 7 months ago


https://github.com/nutriverse/zscorer


Report a bug at https://github.com/nutriverse/zscorer/issues


Browse source code at https://github.com/cran/zscorer


Authors: Mark Myatt [aut] , Ernest Guevarra [aut, cre]


Documentation:   PDF Manual


AGPL-3 license


Imports tidyr

Suggests testthat, knitr, rmarkdown, shiny, shinythemes, covr


See at CRAN
