Create Guitar Tablature

Creates guitar tablature from R code by providing functions for describing and organizing musical structures and wrapping around the 'LilyPond' backend (< http://lilypond.org>). 'LilyPond' is open source music engraving software for generating high quality sheet music based on markup language. 'tabr' provides a wrapper around this software and generates files following the 'LilyPond' markup syntax to be subsequently processed by 'LilyPond' into sheet music pdf files. A standalone 'LilyPond' file can be created or the package can make a system call to 'LilyPond' directly to render the guitar tablature output. While 'LilyPond' caters to sheet music in general, 'tabr' is focused on leveraging it specifically for creating quality guitar tablature. 'tabr' offers nominal MIDI file support in addition to its focus on tablature transcription. See the 'tuneR' package for more general use of MIDI files in R. 'tabr' also provides a collection of helper functions for manipulating and transforming strings of musical notes, pitches, chords, keys, scales and modes.


tabr

CRAN status CRAN downloads Rdoc Travis-CI Build Status AppVeyor Build Status Coverage Status gitter

Overview


Create guitar tablature ("tabs") from R code with tabr. The tabr package provides programmatic music notation and a wrapper around LilyPond for creating quality guitar tablature.

tabr offers functions for describing and organizing musical structures and wraps around the LilyPond backend. LilyPond is an open source music engraving program for generating high quality sheet music based on markup syntax. tabr generates files following the LilyPond markup syntax to be subsequently processed by LilyPond into sheet music.

A standalone LilyPond (.ly) file can be created or the package can make a system call to LilyPond directly to render the guitar tablature output (pdf or png). While LilyPond caters to sheet music in general, tabr is focused on leveraging it specifically for creating quality guitar tablature.

Functionality and support

The tabr package offers the following:

  • Render guitar tablature and sheet music to pdf or png.
  • Write accompanying MIDI files that can respect repeat notation and transposition in the sheet music (under reasonable conditions).
  • Support tablature for other string instruments besides guitar such as bass or banjo.
  • Support for instruments with different numbers of strings.
  • Support for arbitrary instrument tuning.
  • Offers inclusion (or exclusion) of formal music staves above tab staves, such as treble and bass clef staves for complete rhythm and timing information.
  • Track-specific setup for features like instrument type, tuning and supplemental music staves.
  • Provide common notation such as slide, bend, hammer on, pull off, slur, tie, staccato, dotted notes, visible and silent rests.
  • Allows arbitrary tuplet structure.
  • Above-staff text annotation.
  • Percent and volta repeat section notation.
  • Note transposition.
  • Staff transposition.
  • Multiple voices per track and multiple tracks per score.
  • Chord symbols above staff
  • Chord fretboard diagrams and chord chart at top of score.
  • Rich set of layout control options covering settings from score attributions to font size.
  • Optional alternative input format allowing the user to provide string/fret combinations (along with key signature and instrument tuning) to map to pitch.

Note that MIDI support and string/fret alternative input format support are not prioritized in ongoing tabr development. These are considered tangential extra features in tabr that fall outside the general scope and intent of the package.

Installation

You can install tabr from CRAN with:

install.packages("tabr")

You can install tabr from GitHub with:

devtools::install_github("leonawicz/tabr")

Basic example

As a brief example, recreate the tablature shown in the image above (minus the R logo). Here are the steps.

  • Define a musical phrase with phrase or the shorthand alias p.
  • Add the phrase to a track.
  • Add the track to a score.
  • Render the score to pdf with tab.

Constructing a musical phrase

A phrase here does not require a strict definition. Think of it as the smallest piece of musical structure you intend to string together. The first argument to phrase is a string describing notes of a specific pitch (or rests: "r"), separated in time by spaces. For chords, just remove spaces to indicate simultaneous notes. Integers are appended to indicate the octave number so that the pitch is unique. For example, a rest followed by a sequence of notes might be given by notes = "r a2 c3 f3 d3 a3 f3".

The second argument is a similar string giving note metadata. In this example there is nothing to add but the time durations. Whole notes taking up an entire measure of music are given by 1, half notes by 2, quarter notes 4, eighth notes 8, and so on. To specify a quarter note rest followed by a sequence of eighth notes, use info = "4 8 8 8 8 8 8" (or shorten to just info = "4 8*6"). This basic example does not require specifying additional note information such as dotted notes for different fractions of time, staccato notes, ties/slurs, slides, bends, hammer ons and pull offs, etc. These specifications are currently available in tabr to varying degrees of development and are covered in the vignette tutorials.

The third argument, string, is optional but generally important for guitar tablature. In similar format, it specifies the strings of the guitar on which notes are played. Providing this information fixes the fret-string combinations so that LilyPond does not have to guess what position on the neck of the guitar to play a specific note. An inability to specify this in various tablature notation software (or laziness by the user), is a common cause of inaccurate tabs scouring the internet, where even when the notes are correct they are written in the tab suggesting they be played in positions no one would sensibly use. Note that the x shown below is just a placeholder indicating no need to specify a string for the quarter note rest.

The example below employs a couple shortcuts to further reduce typing. The first is to use the * in-string expansion operator mentioned above to avoid typing a long series of eighth notes. Second, it drops explicit reference to octave number three since this central octave is the default octave in LilyPond. This applies to all but the first note below.

While explicit string numbers are not needed for this example, they are provided anyway for full context. Dropping the string argument would further reduce typing.

Score metadata and accessing LilyPond

Finally, specify some song metadata to reproduce the original staff: the key of D minor, common time, and the tempo.

If LilyPond is installed on your system (and added to your system PATH variable on Windows systems), tab should call it successfully. Alternatively, on Windows, it can be added explicitly by calling tabr_options. This option to specify the LilyPond path is still available on other systems. An example of this is commented out below. However, tabr will do its best on package load to set these paths in tabr_options for you if it can successfully detect a LilyPond installation in a standard file system location, so you may not have to do anything. Just check tabr_options() after you load the package. If any of the paths are equal to the empty string "", then you need to set the paths. Otherwise you should be ready to run LilyPond from R.

R code

library(tabr)
# path <- "C:/Program Files (x86)/LilyPond/usr/bin/lilypond.exe"
# tabr_options(lilypond = path) # may not be necessary

p("r a2 c f d a f", "4 8*6", "x 5 5 4 4 3 4") %>% track %>% score %>%
  tab(song, "phrase.pdf", key = "dm", time = "4/4", tempo = "4 = 120")
#> #### Engraving score to phrase.pdf ####
#> GNU LilyPond 2.18.2
#> Processing `./phrase.ly'
#> Parsing...
#> Interpreting music...
#> Preprocessing graphical objects...
#> Interpreting music...
#> MIDI output to `./phrase.mid'...
#> Finding the ideal number of pages...
#> Fitting music on 1 page...
#> Drawing systems...
#> Layout output to `./phrase.ps'...
#> Converting to `./phrase.pdf'...
#> Success: compilation successfully completed

See the pdf result embedded at the tabr website.

Note above that tabr also exports the pipe %>% operator. Even given the hierarchy of objects involved in the series of steps to move from a phrase to a rendered pdf, a short example like this does not even require a single assignment. While music can be quite complex and a full score will be much longer, tabr strives to minimize the work while still forcing some sense of interpretable, organized structure. For long and complex music, it can require some effort and practice to ensure your approach to transcription in your R code is not opaque.

Additional context

Why LilyPond? LilyPond is an exceptional sheet music engraving program. It produces professional, high quality output. It is open source. It offers an access point for a programmatic approach to music notation. It is developed and utilized by a large community. Most GUI-based applications are WYSIWYG and force a greater limitation on what you can do and what it will look like after you do it. On the other hand, I have zero interest in writing LilyPond files. tabr has made it more enjoyable, a bit less ugly, and enables me to stick with LilyPond for its quality as I try to shield myself from its native input structures. I'm sure there are far more LilyPond users who don't mind it at all and have never heard of R; to each their own.

Limitations

There is far more that LilyPond can do that tabr does not tap into. Instead of listing a million things, this is just to highlight an example of a critical feature that still has limited functionality in both tabr and in LilyPond itself: LilyPond's bend engraver. Rendering sheet music with quality string bend notation is quite difficult. This is an area that will benefit greatly from further development.

Reference

There is a rich collection of vignette tutorials available at the tabr website. Complete package reference and function documentation

News

tabr 0.2.0

  • Refactored tuplet (and triplet) to accept a phrase object as well as a character string of notes. Previously, only notes were accepted but this was too limiting. The argument name has changed to from notes to x and tuplet will now check the class of x and handle phrase objects accordingly.
  • Added handling of silent rests in note strings for tuplet.
  • sf_phrase (and sfp) updated to allow returning early with only the notes string as opposed to the entire phrase object. This is useful if you just want a quick, cleaner string representation of what notes are mapped by string/fret combinations.
  • Minor updates to .onLoad for non-Windows systems.
  • Removed tibble package dependency. Using only dplyr suffices.
  • Updated Readme and basic example intro vignette.
  • Added and updated unit tests.
  • Added lintr to Suggests field in DESCRIPTION per CRAN maintainer request regarding testthat unit tests.

tabr 0.1.2 (Release date: 2018-04-18)

  • Unwrapped lilypond example from dontrun tag.
  • Switched to tempdir() location for examples that write files.
  • Added LilyPond to SystemRequirements field in DESCRIPTION.
  • Attempt to run file-writing examples and file-writing unit tests conditionally if LilyPond found on system.

tabr 0.1.1

Adjustments to meet requirements for CRAN resubmission:

  • Updated DESCRIPTION.
  • Adjusted file-writing locations for unit tests to use tempdir.
  • Add dontrun tag around one last file-writing package example that was using lilypond.
  • Update lilypond, tab, midily and miditab to work with system calls that use absolute paths for output files instead of only working with relative paths.

tabr 0.1.0

  • Added package scaffolding.
  • Developed initial functions for music description and organization.
  • Developed initial functions for generating Lilypond (.ly) files and wrapping around system calls to Lilypond for rendering sheet music to pdf or png.
  • Added readme with basic example.
  • Added initial vignette content.
  • Added unit tests.
  • Added support for custom, non-standard guitar tunings and instruments with different numbers of strings, up to seven.
  • Added .mid to .ly and .mid to tab output convenience functions.
  • Added support for multiple voices per staff.
  • Added support for transposition of music staff relative to tablature staff.
