Edit an 'Antares' Simulation

Edit an 'Antares' simulation before running it : create new areas, links, thermal clusters or binding constraints or edit existing ones. Update 'Antares' general & optimization settings. 'Antares' is an open source power system generator, more information available here : < https://antares-simulator.org/>.

Overview

This package provide methods to create (and remove) area, links between them, thermal cluster and binding constraints. These steps maybe usefull before running an Antares simulation.

Install from CRAN:

install.packages("antaresEditObject")

Or install dev version from GitHub :

# with remotes
remotes::install_github("rte-antares-rpackage/antaresEditObject")

# or with install-github.me service (based on remotes) (Works well with RTE proxy)
source("https://install-github.me/rte-antares-rpackage/antaresEditObject")

# or with devtools
devtools::install_github("rte-antares-rpackage/antaresEditObject")

Prerequisites

You need to set the path to an Antares simulation in "input" mode :

antaresRead::setSimulationPath(path = "path/to/study", simulation = "input")

Or you can simply create a new study :

createStudy("path/to/study")

Save simulation

Before modifying your simulation, you can save it in an archive :

backupStudy(what = "input")

This will create a .tar.gz file in your simulation folder.

Create a new area

You can create a new area with :

library("antaresEditObject")

createArea(name = "myarea")

# The new area should appear here :
antaresRead::getAreas()

You can specify the localization of the area on the map, and also color.

There are two helper function for area parameters :

filteringOptions() for filtering options, like filter-year-by-year
nodalOptimizationOptions() for nodal optimizations options.

Create a new cluster

You can initialize a cluster with some parameters :

createCluster(
  area = "myarea",
  cluster_name = "myareacluster",
  group = "other",
  unitcount = 1,
  nominalcapacity = 8400,
  `min-down-time` = 0,
  `marginal-cost` = 0.010000,
  `market-bid-cost` = 0.010000
)

You can edit the settings of an existing cluster :

editCluster(
  area = "myarea",
  cluster_name = "myareacluster",
  nominalcapacity = 10600.000
)

Create a new link

createLink(
  from = "area1",
  to = "area2",
  propertiesLink = propertiesLinkOptions(
    hurdles_cost = FALSE,
    transmission_capacities = "enabled"
  ),
  dataLink = NULL
)

You can edit the settings of an existing link :

editLink(
  from = "area1",
  to = "area2",
  transmission_capacities = "infinite"
)

Create a binding constraint

createBindingConstraint(
  name = "myconstraint",
  values = matrix(data = c(rep(c(19200, 0, 0), each = 366)), ncol = 3),
  enabled = FALSE,
  timeStep = "daily",
  operator = "both",
  coefficients = c("fr%myarea" = 1)
)

Create several Pumped Storage Power plant (PSP)

pspData <- data.frame(
  area = c("a", "b"),
  installedCapacity = c(800,900)
)

createPSP(
  areasAndCapacities = pspData,
  efficiency = 0.75
)

Create several Demand Side Response (DSR)

dsrData <- data.frame(
  area = c("a", "b"),
  unit = c(10,20),
  nominalCapacity = c(100, 120),
  marginalCost = c(52, 65),
  hour = c(3, 7)
)

createDSR(dsrData)

Update general settings

For example, set the output of simulation year by year, and limit the number of Monte-Carlo years to 10 :

updateGeneralSettings(year.by.year = TRUE, nbyears = 10)

Remove methods

You can remove from input folder areas, links, clusters and binding constraints with remove* functions, e.g. :

removeArea("myarea")

Run Time-Series Generator

First, update general settings to activate time series to generate :

updateGeneralSettings(generate = "thermal")

Then run TS-generator:

runTsGenerator(
  path_solver = "C:/path/to/antares-solver.exe",
  show_output_on_console = TRUE
)

Run an Antares simulation

Launch an Antares simulation from R :

runSimulation(
  name = "myAwesomeSimulation",
  mode = "economy",
  path_solver = "C:/path/to/antares-solver.exe",
  show_output_on_console = TRUE
)

News

antaresEditObject 0.1.6

Compatibility with Antares version 7

antaresEditObject 0.1.4

Initial release.
Added a NEWS.md file to track changes to the package.

Reference manual

install.packages("antaresEditObject")

0.2.2 by Veronique Bachelier, a month ago

Browse source code at https://github.com/cran/antaresEditObject

Authors: Veronique Bachelier [aut, cre] , Frederic Breant [aut] , Victor Perrier [aut] , Baptiste Seguinot [ctb] , Benoit Thieurmel [ctb] , Titouan Robert [ctb] , Jalal-Edine Zawam [ctb] , Etienne Sanchez [ctb] , Janus De Bondt [ctb] , RTE [cph]

Documentation: PDF Manual

GPL (>= 2) | file LICENSE license

Imports assertthat, grDevices, data.table, whisker, fs, doParallel, pbapply, parallel

Depends on antaresRead

Suggests testthat, covr, knitr, rmarkdown
